JUNOSe 11.0.x IP, IPv6, and IGP Configuration Guide
76
Response Time Reporter
life Length of the test
source Interface from which the probe is sent
restartTime Restart time of the test in seconds
owner Owner of the probe
samples Maximum number of entries saved in the history table for this
RTR probe
admin Administrative status of the probe: enabled, disabled
tos Setting of the type of service (ToS) byte in the probe's IP header
reactionConfiguration RTR reactions that are configured for the probe
receiveInterface Type and specifier of the interface on which the probe
expects to receive responses; this field is blank if the optional
receive-interface characteristic is not configured
operFail Operation failure event is triggered when this number of
consecutive probe operations is not received or when the operations are
received after a timeout
testFail Test failure event is triggered when this number of probe operations
is not received or when the operations are received after a timeout
timeout Time in milliseconds that the probe waits for a response
tag Identifier configured for the probe
operPerHop Number of RTR probe operations sent to a given hop
maxFail Maximum number of consecutive failures to respond to a probe's
request. When the maximum number is reached, the test stops. Applies only
to pathEcho entries.
hopKpt Number of hops per path for which statistics are collected. When
this number is reached, no additional statistical information about the path
is stored. Applies only to pathEcho entries.
Example
host1#show rtr configuration
rtrIndex type
------- --------
1 echo
2 pathEcho
rtrIndex source
---------- ------------------
1 fastEthernet0/0
2
rtrIndex samples
---------- -------
1 5
2 5
targetAddress reqSize freq
------------ ------ ------ -----
10.5.0.200 1 1
10.5.0.11 1 1
restartTime
-----------
10
60
admin tos reactionConfiguration
-------- --- ------------------------
enabled 0
enabled 0
life
20
30
owner
----------
