Power LED Connector
Connector on the end of the power LED wires attached to the system board.
SPKR
Pin
Signal Name
1
LED_PWR
2
Key
3
Ground
PowerMate Pro150 System
1
3
RST
PWRLED
HDLED
System Harness
Wire Color
Green
Blue
INFRARED
SLP
RP
OM04092
7-13
