TCP/IP Network Settings (Windows, Macintosh, UNIX)
Configuring the Printer Using the ARP/

PING Command

The printer MAC address is required to configure the
printer using the ARP/PING command. The MAC
address can be determined by a status print, from the
sticker on the internal printer network card, or from the
Information menu on the operation panel.
Checking the Printer MAC Address
To find the MAC address using the Status Print, use the
following procedure to print the status print. Load roll
media of A3 size or greater before printing.
Note
The MAC address can be found on the sticker on the
internal print network card, or by pressing the Online
button in the printer operation panel and selecting
MAIN MENU, Information, and then MAC Address.
1
If the printer power is off, press the Power
button to switch the printer on.
Data
Message
After a few moments, Online appears in the display.
5- 10
Information Power
Cleaning
(3 sec.)
Stop/Eject
(1 sec.) Online
Offline
Menu
2
Press the Online button to display MAIN
MENU.
MAIN MENU
Head Cleaning
Cleaning
(3 sec.)
Stop/Eject
(1 sec.) Online
3
Press [ ] or [ ] to select Test Print then
press [ ].
MAIN MENU
↓
Test Print
4
Press [ ] or [ ] to select Status Print, then
press OK button.
Test Print
Status Print
The printer settings information will be printed. When
printing has finished, Online is displayed and the
printer is ready to print.
