Attaching Roll Media - Canon imagePROGRAF W8400 User Manual

Using the Media Take-up Unit
Settings for Using the Media Take-up
Unit
1
Press the Online button to display MAIN
MENU on the printer.
MAIN MENU
Head Cleaning
2
Press [ ] or [
and then press [
MAIN MENU
Take-up Reel
3
Press [ ] or [
press the OK button.
Take-up Reel
Enable
(=) will be displayed to the left of the set value, and
the media take-up unit will be set.
2- 47
Cleaning
(3 sec.)
Stop/Eject
(1 sec.) Online
] to select Take-up Reel,
].
] to select Enable, and then

Attaching Roll Media

1
Set the spool mode switch on the media
take-up unit to Manual.
2
If using the output stacker, remove the two
basket rods at the front, and roll up the stacker
cloth while placing it at the back of the stopper
at the bottom the stand, and then pull the
stacker arm towards you and fold it up.
Make sure that the stacker rods and cloth do not
crush the sensor.
