Printing from Windows
4
Display the Page Setup sheet and do the settings for borderless printing.
Note
Select a document size compatible with borderless printing, and select the Borderless Printing checkbox. The
following dialog box will be displayed. Select the width of the roll media loaded to the printer, and then press the OK
button. Set Borderless Printing Method in Scale to fit Roll Paper Width.
If performing borderless printing to images for which there are blanks at the top and bottom of the print data, combine
printing with the No spaces at Top or Bottom (conserve paper) function in the Layout sheet for simpler borderless
printing than borderless printing with no margins at top, bottom, left, or right. For details, refer to
and Bottom Margins (Conserve
3- 19
1 Select the size of the original created in the software application
using Page Size.
2 Select the Borderless Printing checkbox.
* In this example, A4 and document sizes that are not compatible with
borderless printing have been selected.
* Set Borderless Printing Method in Scale to fit Roll Paper Width.
3 To change the roll media width setting, select using the Roll
Paper Width list.
* The settings details will be supplied in the settings preview.
Paper)". (→ P.3-39)
