Canon imagePROGRAF W8400 User Manual page 402

Print Quality Functions
Correcting Image Offset
If vertical lines are bent, or when colors are faded and
uneven, execute Auto Head Adj. to correct the position of
the printhead. The printer prints a printhead adjustment
pattern and read the pattern as it prints to correct the
position of the printhead automatically.
Online
Online
Offline
Online
MAIN MENU
Adjust Printer
Auto Head Adj.
Advanced Adj.
* Adjusting Gaps Between
Odd/Even Nozzles, Print-
ing Direction, Color Gaps
Yes
Online
Printing
Online
7- 9
Standard Adj.
* Adjusting Print Direction
No
OK OK
Correcting Horizontal Banding in
Images
Execute Adjust Band to adjust the amount of media feed and
correct undesirable horizontal banding in printouts. The printer
prints a media feed adjustment pattern and scans it as it prints
to correct the amount of media feed automatically.
Execute Adjust Band, after Feed Priority is set to Band
Joint, if you want to adjust the amount of media feed.
Online
Online
Offline
Online
MAIN MENU
Adjust Printer
Feed Priority
Band Joint
OK
Adjust Band
Standard Adj.
* Standard Feed Adjustment
Yes
Online
Printing
Online
Advanced Adj.
* High-Precision Feed Adjustment
No
OK OK
