Printing with Rolls Media
13
If the roll media remaining detection feature
is ON, press [
of the loaded media, then press the OK
button.
For roll media lengths, refer to the manual that
accompanies the roll media.
If you have loaded roll that has a barcode showing
the remaining length printed on it, the amount of
media remaining is detected automatically so you do
not need to make any settings.
Roll Length Set
30.0 m
After a few seconds, Online is displayed and the
printer is ready to print.
Important
If you changed the paper type, make sure to adjust the
paper feed amount. (→ P.4-43)
Note
The printer adjusts the paper feed amount minutely for
each media type to deliver optimum print quality.
Consequently, the image size and margins may
change according to the paper type.
2- 34
] or [ ] to detect the length
→

Selecting the Media Type

If you have loaded paper into the printer, make sure to
set the paper type using the operation panel. You cannot
achieve accurate printing results is the paper type is
incorrect. If the printer paper type settings are incorrect,
the settings can be changed using the following
procedure.
1
Press the Online button to display MAIN
MENU on the printer display.
MAIN MENU
Head Cleaning
Cleaning
(3 sec.)
Stop/Eject
(1 sec.) Online
2
Press [ ] or [ ] to select Media Type,
then press [ ].
MAIN MENU
↓
Media Type
