Using the Media Take-up Unit
6
Insert the slide holder axle into the left side of
the tube, then push on the right side of the
slide holder until you hear a clicking sound,
then push the holder firmly until it locks.
Push the slide holder until the left and right holder
axles (h) are fully seated.
g
Important
Take care not to catch the slide holder release lever (g)
while you are pushing the slide holder. The holder will
not be completely fixed in place, and may cause
defective spooling.
After firmly pushing in the slide holder, check that the
tube is not loose. If the paper moves left and right, and
there is a height difference between surfaces (h) and
(i), remove and reset the conduits.
2- 49
h
i
7
Press the Online button to display MAIN
MENU on the printer display.
MAIN MENU
Head Cleaning
Cleaning
(3 sec.)
Stop/Eject
(1 sec.) Online
8
Press [ ] or [ ] to select Auto Feed, and
then press [ ].
MAIN MENU
↓
Auto Feed
9
Press [ ] or [ ] to select Yes, and then
press the OK button.
Auto Feed
Yes
(=) will be displayed to the left of the set value, and
the roll media will be fed to the media take-up unit.
