Replacing the Printhead
11
Remove the old printhead.
Caution
If you are going to replace the printhead immediately
after printing, wait a few minutes before starting the
work. The metal parts of the printhead may be hot
immediately after printing, and touching these parts
could cause a minor burn.
Important
Never touch the electrical contacts on the carriage.
Doing so may damage the printer.
4- 24
12
Grasp the new printhead knob (e) and
remove the printhead from the case, and
then remove the orange safety cap 1 (f).
e
13
Press and hold down the knobs (h) on both
sides of the safety cap 2 (g) on the new
printhead, and then pull the cap down to
remove it.
g
TOP
Chapter 1
Basic Use
Chapter 2
Using Various Media
f
Chapter 3
Printing by Objective
Chapter 4
Maintenance
Chapter 5
Using the Printer
in a Network
Environment
Chapter 6
Troubleshooting
Chapter 7
Operating the
Function Menu
h
