Set Sensor Parameters, Web Interface
6.2.2

Triggering Data Acquisition

6.2.2.1

General

The data recording on the confocalDT IFD241x can be controlled using an external electrical trigger signal or com-
mands.
- The triggering does not affect the preselected measuring rate.
- Factory setting: no triggering, the controller starts with the data transmission output immediately after being switched
on.
- The pulse of the trigger signal is at least 5 µs.
Sync /
Multifunction input 1 / 2
Software
Encoder 1
Inactive
Level triggering
. Continuous data recording/output as long as the
selected level is present. After that, the controller stops the data recording.
The pulse duration must be at least as long as one cycle. The subsequent
pause must also be at least as long as one cycle.
W = Displacement signal
Triggering with active high level (U
Fig. 42
and digital signal (D )
0
Edge triggering
. Starts measured value input/output as soon as the
selected edge is active to the trigger input. The pulse must be at least 5 µs.
Triggering with falling edge (U
Fig. 43
digital signal (D )
0
Software triggering.
Initiate trigger
button is activated.
Encoder triggering.
6.2.2.2

Triggering Measured Value Acquisition

The current array signal is only processed and measured values are calculated from it after a valid trigger event. The
measurement data is then transferred for further calculation (e.g. averaging), as well as the output via a digital or analog
interface.
When calculating averages, measured values immediately before the trigger event cannot be included; instead older
measured values are used, which had been entered during previous trigger events.
Fields with gray background require a selection.
confocalDT IFD2410/2411/2415
Level
Trigger type
Edge
), associated analog signal (A
I
), associated analog signal (A
I
Starts data recording as soon as a software command (instead of the trigger input) or the
Starts the data recording through Encoder 1.
Trigger level
Trigger level
Number of measured
values
Number of measured
values
Lower limit
Upper limit
Increment
Continuous data recording
)
0
) and
0
Value
Fields with dark border require entry of a value.
Low / falling edge
High / increasing edge
manual selection Value
infinite
manual selection Value
infinite
Value
Value
Value
U
I
W
A
0
D
0
U
I
W
A
0
D
0
t
t
t
t
t
t
t
t
