驱动器设置
2. Install ServoStudio2 software on the host computer.
3. After installation is complete, launch ServoStudio2 from the Windows Start menu or from
the shortcut on the desktop.
If an error appears when installing software and the system cannot find the file specified, please
do the following:
Copy the installation file to the computer hard disk.
⚫
Right-click the installation file and select "Run as administrator."
⚫
Install USB device driver of CDHD2S.
The first time you connect a drive to a host through a USB port, Windows may display the New
Hardware Discovery wizard, or a new driver will be added to Windows Device Manager with an
error or warning symbol.
1. If Windows activates the "New Hardware" wizard, press "Skip getting drives from the
network" when this prompt appears. Open Windows Device Manager.
2. In the Ports or Universal Serial Bus Controllers section, find the device marked "Unknown".
3. Right-click on the unknown device and select "Update Drive".
4. Select "Browse my computer" and browse to the following location:
C:\ProgramFiles(x86)\Servotronix\ServoStudio2\Drivers\
5. Make sure the "Include subfolders" option is checked, then click "Next."
6. When the Windows prompt appears, click "Install."
The USB driver has two layers, and you may need to repeat the "Update Drive" procedure
again.
Note:
CDHD2S USB drives are digitally signed.

4.4.6 Fieldbus device files

EDS file of CDHD2S on the host computer or PLC controller (if CAN protocol is used).
⚫
Download from the Servotronix website or contact technical support.
XML file of CDHD2S on the host or PLC controller (if EtherCAT protocol is used).
⚫
Download from the Servotronix website or contact technical support.
GSD file of CDHD2S on the host computer or PLC controller (if PROFINET protocol is
⚫
used). Download from the Servotronix website or contact technical support.
—38—
