CDHD2S Accessories

11. CDHD2S Accessories

11.1 Mating Connector Kit

CDHD2S (medium-voltage) power supply mating 1.5A, 3A, AC voltage
CDHD2S (medium-voltage) power supply mating 4.5A, 6A, AC voltage
CDHD2S (medium-voltage) power supply mating 8A, 10A, 13A, AC voltage
CDHD2S (medium-voltage) power supply mating 20A, 24A, AC voltage
CDHD2S (low-voltage) power supply mating 3A, 6A, 12A, 15A, AC voltage
CDHD2SC2 - controller interface MDR36 pin
CDHD2SC3 – machine interface MDR20 pin

11.2 Cable

Note: It is strongly recommended that you use the USB cable provided by Servotronix, which
has been tested and proved to be reliable..
Item
USB2.0A to Mini-B cable
Shielding
Twisted pair cables
Maximum length
Wire gauge
EMI filtering
Item
USB2.0A to Mini-B cable
Shielding
Twisted pair cables
Maximum length
—263
—
Description
120/240V, spring
120/240V, spring
120/240V, crimped
120/240V, spring
20/90V
CDHD2SC4 – feedback MDR26 pin
CDHD2SSTO connector
Table 11-2 C1 - USB2.0A to Mini-B cable
Specification
85% copper braided wire shield
2 ferrite cores, located near each
Table 11-3 C2 - controller interface cable
Specification
85% copper braided wire shield
Table 11-1
coverage
Required
3m
20–28AWG
connector
coverage
Required
3m
Servotronix part number
KIT-2A-PWSPR-00
KIT-2B-PWSPR-00
KIT-2C-POWER-00
KIT-2D-PWSPR-00
KIT-1D-POWER-00
KIT-C2MDR36000
KIT-C3MDR20000
KIT-C4MDR26000
KIT-00P1000-00
Servotronix part number
CBLr0000USBA-00
Servotronix part number
CBLr0000USBA-00
