For other models, no additional tools are required.

4.4.2 Cables and crimping

Please refer to the Cables section for details of the various cables required by the CDHD2S
system.
Before crimping, strip 2mm off the end of the wire, as shown in Figure 4-1.

4.4.3 Connector - control board

For more information about cables, Please refer to the Cables section.
Interface Manufacturer
C2 3M
3M
Interface Manufacturer
C3 3M
3M
—35—
High-voltage type – AC voltage 400/480V
Item
Crimping pliers
Crimping pliers
Figure 4-1 Wire insertion into crimp pin
Table 4-2 Connector for controller interface C2
Item
Welding plug connector
Welding plug shell
Table 4-3 Connector for machine interface C3
Item
Welding plug connector
Welding plug shell
Model
CDHD2S-012
CDHD2S-024
CDHD2S-030
Molex0638190000(P1,P2
)
(alsoP3onCDHD2S-
024/030)
CDHD2S-024
CDHD2S-030
Molex0638190000
Manufacturer
part number
10136-3000PE
10336-52F0-008
Manufacturer
part number
10120-3000PE
10320-52F0-008
Interface
P1, P2
P3
Servotronix
part number
CONr00000036-01
HODr00000036-00
Servotronix
part number
CONr00000020-38
HODr00000020-00
