Troubleshooting
Warning#
Number
WRN53
WRN54
WRN55
WRN56
WRN57
WRN58
WRN59
WRN60
WRN61
WRN62
WRN63
WRN64
WRN65
WRN66
WRN67
WRN68
WRN69
WRN70
Warning message (click description for more information)
Conflicting digital inputs are turned on
Fan circuit warning
Blower circuit overloaded or disconnected
Excessive electrical noise warning
System produces excessive electrical noise
Feedback type mismatch
The configured feedback type and the connected encoder do
sensAR encoder over-temperature warning
sensAR encoder over-temperature warning
sensAR encoder built-in flash memory failure
sensAR built-in flash memory failure
An excessively high axis shift is detected.
The device has detected abnormally high axis shift
Gantry paired axis positive limit switch
The second gantry axis has reached the forward hardware or
software limit switch
Gantry paired axis negative limit switch
The second gantry axis has reached the negative hardware or
software limit switch
Internal axis synchronization lost (without HMI)
Internal FPGA communication synchronization problem
Motor foldback disabled
A connection between the controller and the drive is
Reconnect the controller and drive
LOAD failure parameter set to default value
LOAD failure parameter set to default value
Inter-drive communication warning
There is a synchronization loss or timeout error at the inter-
drive communication layer
Too many communication errors
Too many consecutive errors, check errors , or timeout errors
Gantry does not receive PFB reply from partner axis
The axis sends position feedback data to the partner axis, but
the partner axis does not acknowledge receipt.
Multi-turn encoder battery voltage low
During the secondary feedback, the battery voltage is close to
the fault level. Replace the battery as soon as possible.
Knlusergain switch threshold configured incorrectly
Knlusergain switch threshold configured incorrectly
not match
removed
