CDHD2S Accessories
Function
CAN high
CAN low
Functional ground
CAN shield
Functional ground
CDHD2S adapter CAN, D9 to RJ45
CDHD2S adapter DB95, RJ45/jack 8 contacts

11.4 Line filter

The recommended line filter manufacturers and part numbers of CDHD2S are listed in the
following table.
High-voltage model
Main line
Manufacturer
part number
Manufacturer
part number
Figure 11-2D9-RJ45 adapter interface
Table 11-11 D9-RJ45 adapter wiring
CDHD2SRJ45 pin
1
2
3
6
7
Table 11-12 D9-RJ45 adapter
Description
Table 11-13 Recommended line filters
CDHD2S-012
Three phase
LCR
096B.02001.00
CORCOM
25FCD10
D9 connector pinout
7
2
3
5
6
Servotronix part number
ADPrCAN_D9|RJ45
ADPr0AMK0001-00
CDHD2S-024
Three phase
LCR
096.03501.00
LCR
096B.03001.00
CDHD2S-030
Three phase
LCR
096.03501.00
LCR
096B.03001.00
—266
—
