Specifications
Single or three phase
AC 120/240V
Control circuit input power
(L1C, L2C)
STO (safety torque
shutdown)
STOFuse(TimeDelay)
Drive output
Soft start
Circuit power loss
Control circuit loss
Total power loss
Hardware
Unit weight
Connecting hardware
Line number
Installations
Net distance
Voltage trip
Power supply temperature
Fan
Power module
External regenerative
resistor
(B1+, B2)
External regenerative
resistor requirements
—25—
Specification
Continuous current (1 phase/3 phase,
Arms)
Line fuse (FWP, or equivalent)
Voltage-endurance (primary to
ground)
120±10 or 240±VAC
STO power supply (DC voltage)
120 or 240 VAC (A)
Continuous output current [Arms]
Continuous output current (Apeak)
Peak output current (Arms) 2s
Peak output current (Apeak) 2s
kVA, 120V AC voltage
kVA, 240V AC voltage
PWM frequency (kHz)
Maximum soft-start surge current (A)
Maximum charging time (ms)
W
W
W
kg
PE grounding screw size/torque
Control circuit (AWG) (under 3 meters)
Main circuit motor circuit (AWG)
Main circuit AC input (AWG)
PE grounding screw
Installation of Book
Left and right (mm)
Top/bottom (mm)
Low voltage trip (nominal) (DC
voltage)
Overvoltage trip (DC voltage)
Usually run at a quarter of power;
when the temperature exceeds the
trigger temperature of the high-speed
fan, it works at full power.
Temperature to trigger high-speed
fan (°C)
Overheating fault regulation (°C)
power module
Overheating fault unregulation (°C)
power module
Peak current (A)
Minimum resistance (Ω)
Medium-voltage Medium-voltage
CDHD2S-4D5
8.5/4
10
1500VAC (2121VDC) 1500VAC (2121VDC)
Single phase
24±10%
1.5
4.5
6.63
18
25.45
0.5
1.1
16
7
250
5
0.97
M4/1.35Nm
24-28
16
16
M4
15
50
100
420
Yes
45
80±5%
NA
25.5
16
CDHD2S-006
10/5.8
10
Single phase
24±10%
1.5
6
8.48
18
25.45
0.7
1.5
16
7
250
5
0.97
M4/1.35Nm
24-28
16
16
M4
15
50
100
420
Yes
45
80±5%
45
25.5
16
