Safety and Standards
Note: PN version only has 1.5A, 3A, 4.5A and 6A 220V MV models.

1.4 CDHD2S Product Label

Different models of products may look exactly the same. See the product label on the back
panel of the drive for model numbers and specifications. The following picture shows the EtherCAT
model label.
Model: CDHD2S-0244DEC2
Serial number: 118B-0000012
AC voltage
Frequency Hz
F.L. current 3PH
Power 380/480V
The following picture shows the PROFINET model label.
Model：CDHD2S-0032APN2
Serial number: 118B-0000012
AC voltage
Frequency Hz
F.L. current 3PH
Power 120/240V
Rating Input
380/480 3PH
50/60
24A
Residual voltage. To avoid electric shock,
Dangerous please wait 5 minutes after removing the
voltage power supply before performing
maintenance.
Read the manual and follow the safety
Warning instructions. Use proper PE grounding
techniques.
Do not touch the radiator. It may cause
Hot surface
burns.
www.servotronix.com
Figure1-3 EtherCAT model label
Rating Input
120/240 3PH
50/60
5A
Version:
Output
380/480 3PH FW: 2.0.0
0-1000Hz SCCR: 5000A
IP20 housing
24A
protection
Ambient
12.2/15.4kVA
temperature: 45℃
Ref:PRD9HCD3MC2-00
Version：
Output
FW：2.0.0
0~240 1PH
0-1000Hz SCCR：5000A
IP20 housing
3A
protection
Ambient
0.44/0.74kVA temperature：
45℃
