Motor Setup
"Negative" and "Positive" start the drive and run the motor!
2. To reverse the direction to match the system, enable the Inverse Direction option. Please
refer to the VarComMPHASE and DIR.
3. To complete the process, click Save or Done.
Motor Setup - Save
After completing the "Motor Setup", it is recommended that you save the parameters to the
non-volatile drive memory and a file on the host for backup.
Do both of the following:
Click Save to Drive to save the parameters in the drive RAM to its permanent memory.
⚫
Click Save to PC to save the parameters in the drive RAM to a backup file on your
⚫
computer. Parameters are saved in text files with TXT or SSV extension. Text files can be
edited using Notepad or any other text editor.
It is also recommended that you create an application report:
Click Generate Report.
⚫
When activated, Report Generator will open a dialog box that allows you to enter application
and user information. Then generate a set of CSV and TXT files in the compressed file. This file can
be attached to an email automatically sent to technical support. You can change the address and
send it to other recipients.
Please refer to the Report Generator in the ServoStudio2 manual.

5.2 Drive Identification

You can see and confirm drive information in the Motor Setup wizard.
The ServoStudio2 Drive Information screen allows you to view drive properties and define the
drive name. The following parameters are used to view and configure drive information:
VarCom
Figure 5-7 Motor setup wizard - save
Table 5-1
Description
—114
—
