4.4.5 Host system

The following computer systems and software are required:
2GHzCPU
⚫
1GBRAM
⚫
1000MB of free hard drive space (after installing .net4)
⚫
Communication interface to the drive; one of the following:
⚫
USB port
◼
USB port and USB-to-RS232 adapter (with ferrite beads)
◼
RS232 port
◼
Operating system: Windows7, Windows8, Windows10, 32-bit or 64-bit.
⚫
For ServoStudio2, the recommended screen resolution is 1280x800; the
⚫
minimum resolution is 1024x800.
It is recommended to set your Windows monitor to small - 100% (default).
⚫
Net4 (please refer to the .NET Framework System Requirements for details).
⚫
If .NET4 is not installed on your computer, ServoStudio2 will guide you through
the installation but will not install it automatically.
ServoStudio2, a graphical software interface for configuring and testing the
⚫
drive. Download from the Servotronix website or contact technical support.
Please refer to Software Installation in the ServoStudio2 manual.
Note: ServoStudio2 provides compatibility with CDHD2S firmware version 2.0 and
above.
Install ServoStudio2
1. Download the ServoStudio2 software installation file from the Servotronix website or contact
technical support.
—37—
Function
Crimp connection 15EDGKNM-3.5-
STO 04P-14-1022Z (H)
Wire diameter: 16-28AWG
Crimp connection 15EDGKNM-3.5-
STO2 04P-14-1022Z (H)
Wire diameter: 16-28AWG
Crimp connection 15EDGKNM-3.5-
02P-14-1000A(H)
Wire diameter: 16-28AWG
Housing: SPC5/2-STCL-
Wire diameter: 14-17AWG
Housing: SPC5/6-STCL-
interface Wire diameter: 12-14AWG
Housing: SPC5/3-STCL-
interface
Wire diameter: 12-14AWG
Manufacturer
part number
7,62(1718481)
7,62(1718520)
7,62(1718494)
Servotronix
part number
11201707001435
11201707001435
11201707001436
CONr10000002-16 or
11201707000304
CONr00000006-78 or
11201707000306
CONr10000003-21 or
11201707000305
