1.5 CDHD2S File Package

The CDHD2S servo drive's file package contains the following manuals.
The CDHD2S manual can be downloaded from the product page of the Servotronix website
(http://www.servotronix.com/products/cdhd-servo-drives/).
CDHD2S User Manual: Hardware Setup, Operation and Tuning.
⚫
For use by those qualified to transport, assemble, consign and maintain drives.
ServoStudio2 Reference Manual: Graphical User Interface (GUI) provided with CDHD2S for
⚫
configuring, operating and tuning the drive.
VarCom Reference Manual: Parameters and commands used to configure, operate and tune
⚫
the drive.
EtherCAT and CANopen Reference Manual.
⚫
The CDHD2S implements the CANopen protocol used by the CDHD2SEtherCAT (EC and EB)
and CAN (AF) drives.
The files can also be found in the online help package included with the
Note:
ServoStudio2 software.
Residual voltage. To avoid electric shock,
Dangerous please wait 5 minutes after removing the
voltage power supply before performing
maintenance.
Read the manual and follow the safety
Warning instructions. Use proper PE grounding
techniques.
Do not touch the radiator. It may cause
Hot surface
burns.
www.servotronix.com
Figure 1-4 CDHD2S product label - sample
Ref:PRD9HCD3MC2-00
