CHAPTER 1 – INTRODUCTION
The Matrix Pro GS allows the management of multiple connected modules plus GNSS mapping, Guidance, FieldPilot
Control, and data collection in a single console using CAN bus technology. This replaces multiple consoles in the cab with one robust system.

Product Upgrades Available

® ®
• FieldPilot or FieldPilot Pro auto steering
• UniPilot ® or UniPilot ® Pro assisted steering
• BoomPilot ® automated boom section control
• Tilt Gyro Module
• Video Selection Modules for up to 8 cameras

SYSTEM COMPONENTS

Matrix Pro 570GS Console

The Matrix Pro 570GS is designed to provide years of service under typical agricultural operating conditions. A tight fitting enclosure,
combined with rubber covers for all connectors mean that typical dusty environments will not cause operational problems. While occasional
splashing of water will not damage the unit, the Matrix Pro 570GS is not designed for direct exposure to rain. Take care not to operate the
Matrix Pro GS in wet conditions.
Figure 1-1: Matrix Pro 570GS Console Front and Back
Standard RAM bracket
(assembly required)
Matrix® Pro 570GS ● Matrix® Pro 840GS
• External GNSS receiver or antenna upgrades
• Fieldware
• Pressure Sensor Interface Kit for Droplet Size Monitor
• Third Party Rate Control
Built in lightbar
Power button
USB port with rubber cover
Bright touch screen
Speaker
Power button
Integrated RAM mount
(assembly required)
USB port with rubber cover
Recessed connectors
Link enhanced data organization application
®
GPS antenna connection
Rubber connector covers
Speed dignal connection
Camera connection
Power connection
