Matrix® Pro 570GS ● Matrix® Pro 840GS

NAVIGATION SCREENS

Guidance and navigation can be accessed from the Vehicle View screen, Field View screen, or RealView screen.
• Press NAVIGATION AND GUIDANCE OPTIONS tab
• Press REALVIEW OPTIONS tab
Figure 7-5: Guidance Screen Options
-13
-13
Home/Job Screen
(or press Home Button)
Unit Setup
Vehicle View Guidance
Field View Guidance
RealView Guidance
62
www.teejet.com
to display navigation options.
to display camera setup and guidance options.
12
0.0
deg
12
0.0
deg
Navigation and Guidance Options
A
A
B
Zoom in/out icons are not available on Matrix Pro 840GS
or on RealView guidance screens
RealView Options
