Matrix® Pro 570GS ● Matrix® Pro 840GS
APPENDIX D – SETTING RANGES
Press the option's name of any menu item to display a definition and range values of that item.
Figure A-3: Example of Information Text Box
APPENDIX E – UTM COORDINATES AND ZONES
The Matrix® Pro 570GS and Matrix® Pro 840GS use the Universal Transverse Mercator (UTM) coordinate system to track job locations. The
UTM coordinate system divides the surface of the Earth into sixty numbered north-south zones, which are further divided into latitude zones
designated by letters, as shown below.
Figure A-4: UTM Coordinate System – Global
The Matrix Pro GS console then tracks the UTM zones in which each product application job is performed. This zone information is then used
to determine whether a job can be started/continued or to find the saved job that is closest to the vehicle's current position.
If a selected job is in a UTM zone other than the current or adjacent UTM zone, "Out of Range" will be displayed next to Distance, and
or will be disabled.
Start Job Continue
If a selected job has no recorded information, Distance will show "No Data".
