Droplet Size Monitor - TeeJet Technologies MATRIX PRO GS User Manual

Figure 4-7: Implement – Multiple Sections with SDM or SFM Setup
Matrix® Pro 570GS ● Matrix® Pro 840GS

Droplet Size Monitor

When the system includes a Pressure Sensor Interface Kit (PSIK),
or a Dual Control Module with Product Control Application Type set
to "Liquid" and the Primary Sensor or a Monitor set to "Pressure",
Droplet Size Monitor can be enabled/disabled. The DSM then
becomes available on the operation screens.
NOTE: For more information, see "Droplet Size Monitor" in the
1. Press CONFIGURATION side tab
2. Press
3. Select if Droplet Size Monitor is enabled or disabled. (If enabling,
also read displayed information and press
4. Press RETURN arrow
return to the main Configuration screen.
Figure 4-8: Droplet Size Monitor
Implement chapter of this manual.
.
Implement
or CONFIGURATION side tab
