Matrix® Pro 570GS ● Matrix® Pro 840GS
Keyboard Entry Screen
Press the KEYPAD icon
. Use the numeric keypad to enter
a value.
Press the ACCEPT icon
to save the settings or the
CANCEL icon
to leave the keypad without saving.
Figure 1-12: Example of Keyboard
GNSS Antenna Height (ft)
1
4
7
0
6
www.teejet.com
12.5
2
3
Clear
5
6
<--
8
9
.
+/-
Next Page
Press the NEXT PAGE arrow
selected item.
Figure 1-13: Example of Next Page
Checkboxes
Press the CHECKBOX
/
Figure 1-14: Examples of Checkboxes
to set up additional options for the
to select or deselect.
