Transfer

The machine settings transfer screen allows the transfer of selected
machine settings to or from a USB drive, as well as deleting
machine settings.
Machine settings transferred to a USB storage device can be opened
and updated using Fieldware Link. From Fieldware Link, machine
settings can be ported back to a USB storage device to be moved
back onto the console internal storage for use.
NOTE: Not all settings saved as part of the machine settings are
available to be edited in Fieldware Link. See the setting
availability chart for details.
Machine settings transferred to a storage device are
removed from the console and are no longer available
for use.
1. Press DATA MANAGEMENT side tab
Machine Settings
2. Press .
3. Press .
Transfer
4. Select from:
►Move Machine Settings to USB Storage
machine settings from internal storage to USB
►Move Machine Settings to Internal Storage
move machine settings from USB to internal storage
►Delete Machine Settings
settings from internal storage or USB storage
5. Press RETURN arrow
to return to the main Data Management screen.
tab
Figure 4-31: Machine Settings – Transfer
Matrix® Pro 570GS ● Matrix® Pro 840GS
.
– used to move
– used to
– used to delete machine
or DATA MANAGEMENT side

Manage

The Machine Settings Manage screen allows the creation of a new
empty machine settings, the copying of a selected machine settings
to a new machine settings, the deletion of a selected machine
settings, the saving of the current machine settings to the selected
machine settings, or the loading of the selected machine settings to
the current settings.
NOTE: Not all settings are saved as part of the machine settings.
See the appendix "Matrix Pro GS Console Menu Settings"
for details.
1. Press DATA MANAGEMENT side tab
Machine Settings
2. Press .
Manage
3. Press .
4. Select from:
►New – used to create a new machine setting with no
associated implement information
►Copy – used to copy a selected machine settings into a new
machine settings
►Delete – used to delete a selected machine settings from
internal storage
►Save – used to save the current machine settings to the
selected machine settings
►Load – used to load the selected machine settings to the
current settings
5. Press RETURN arrow
to return to the main Data Management screen.
tab
Figure 4-32: Machine Settings – Manage
.
or DATA MANAGEMENT side
