Program

Program allows direct programming of the GNSS receiver through a
command line interface. Only TeeJet support technicians should use
this feature. Use at your own risk!
1. Press .
Start
2. Adjust programming as required.
Figure 5-6: Programming Receiver

PRN

PRN selects the SBAS PRN that will provide GNSS differential
correction data.
1. Press DOWN arrow
to access the list of options.
2. Select:
►Automatic – automatic PRN selection
►Number – contact your local dealer for the number associated
with your operating location
Figure 5-7: PRN
Matrix® Pro 570GS ● Matrix® Pro 840GS

Alternate PRN

When PRN is not automatic, a second alternate SBAS PRN will
provide a second set of GNSS differential correction data.
1. Press DOWN arrow
2. Select:
►None – no alternate PRN number
►Number – contact your local dealer for the number associated
Figure 5-8: Alternate PRN

PRN Not Shown

PRN options are only available with SBAS GNSS Type selected.
Figure 5-9: PRN Not Shown
to access the list of options.
with your operating location
98-05273-ENUS R6
37
