CHAPTER 7 – GUIDANCE
The Matrix Pro GS allows product application and vehicle guidance to be performed simultaneously. Once unit setup is complete, guidance can
begin. Five guidance modes allow the operator to optimize the field work: Straight AB
. Additional optimization can be accomplished with Boundary Application
NextRow
and RealView Guidance Over Video
Three guidance screens assist in keeping you informed.
Vehicle View Guidance creates a computer-generated image of
the vehicle position displayed in the application area.
7.62
0.0
ac
Field View Guidance creates a computer-generated image
of vehicle position and application area from an aerial perspective.
7.62
Mark A
ac
RealView Guidance allows live video input to be displayed instead
of a computer-generated image.
7.62
0.0
ac
56
www.teejet.com
.
6.1
mph
6.1
mph
6.1
mph
, Curved AB
, Curved Lookahead
To choose a Guidance Mode:
1. Press NAVIGATION AND GUIDANCE OPTIONS tab
display navigation options.
2. Press GUIDANCE MODE icon
3. Select from:
►Straight AB Guidance
►Curved AB Guidance
►Circle Pivot Guidance
►Last Pass Guidance*
►NextRow Guidance*
►No Guidance
* Guidance options may not be available depending on
assisted/automatic steering system installed.
Figure 7-1: Choose a Guidance Mode
0.00
Mark A
ac
0.00
Mark A
ac
, Circle Pivot , Last Pass
, Return to Point Guidance
.
