Boompilot Icon - TeeJet Technologies MATRIX PRO GS User Manual

BoomPilot Icon

The BoomPilot Icon is used to activate an icon in the Navigation and
Guidance options on the guidance screens for manually controlling
BoomPilot
1. Press CONFIGURATION side tab
2. Press .
Implement
3. Press DOWN arrow to select Enable or Disable.
◄Enable – BoomPilot Icon will be available in the Navigation
and Guidance options on the guidance screens to control
automatic section control
◄Disable – BoomPilot Icon will not be available in the Navigation
and Guidance options
Figure 6-37: BoomPilot Icon
Figure 6-38: BoomPilot Icon on Guidance Screen
0.0
Mark A
mph
Matrix® Pro 570GS ● Matrix® Pro 840GS
.
0.00
ac
A
55
98-05273-ENUS R6
