GETTING STARTED
#1 Turn Power On
Press the POWER button
#2 Home Screen
Once the power up sequence has completed, the Home screen will appear with
the option to start a new job or continue an existing job.
#3 Go to Unit Setup
1. Press UNIT SETUP bottom tab
The Configuration options will be displayed first. Data management
Console settings and Tools
Cultural Setup
1. Press CONSOLE side tab
2. Press .
Cultural
Culture is used to configure units, language and time zone settings.
GNSS Setup
1. Press CONFIGURATION side tab
GNSS Receiver Configuration
2. Press
GNSS is used to configure GNSS type, GNSS port and PRN as well as
to view GNSS status information.
Implement Setup
1. Press CONFIGURATION side tab
2. Press .
Implement
Implement setup is used to establish the various settings associated
with straight mode, spreader mode or staggered mode. Settings will
vary depending on if an AutoSteer or BoomPilot system is present.
AutoSteer Setup
1. Press CONFIGURATION side tab
2. Press .
AutoSteer
When a Steering Control Module (SCM or SCM Pro) is present,
assisted/auto steering options will be available. For detailed setup
instructions, refer to your specific AutoSteer installation manual.
#4 Go to Guidance Screen
1. Press VEHICLE VIEW GUIDANCE tab
GUIDANCE tab
2. Press NAVIGATION AND GUIDANCE OPTIONS tab
navigation options.
Choose a guidance mode
►Straight AB
►Curved AB
►Circle Pivot
Mark A and B Points
To establish a AB guideline.
to power on the console.
.
can be accessed through the side tab keys.
.
.
.
.
.
, FIELD VIEW
or REALVIEW GUIDANCE tab
►Last Pass
►NextRow
A B
#2
,
#3
.
#4
to display
10.0
0.0
mph
A
27.00
ac
A
A
