Matrix® Pro 570GS ● Matrix® Pro 840GS

SIMPLE MODE

Once the power up sequence has completed, the Home screen will
appear with the option to start a new job or continue an existing job.
The console must have GNSS before starting or continuing a job.

New Job

Starting a new job will clear the previous job data.
To start a New Job:
1. On the Home screen , press
The console will jump to Vehicle View.

Continue Job

To continue the existing job:
1. On the Home screen , press
The console will jump to Vehicle View and begin providing navigation
information.
If a selected job is in a UTM zone other than the current or adjacent
UTM zone,
will be disabled.
Continue
NOTE: For more information, see the UTM Zone Appendix.

Close Job

To close a job:
1. On the Home screen , press
To create a report of the job when closing a job:
1. Insert a USB drive into the USB port of the console.
2. On the Home screen , press
3. Select:
►Yes – to create a report of the last job
►No – to return to the Home screen without saving
8
www.teejet.com
.
New Job
.
Continue
.
Close Job
.
Close Job

ADVANCED MODE

Once the power up sequence has completed, the Home screen will
appear with the option to start a new job or continue an existing job.
The console must have GNSS before starting or continuing a job.
New Job
Starting a new job will clear the previous job data.
To start a New Job:
1. On the Home screen , press
2. Press:
►Yes – to automatically generate a name
►No – to enter a name using the on screen keyboard
Client, farm, and field information are inputted using Fieldware Link.
The console will jump to Vehicle View.

Start Job

The Matrix Pro GS is programmed with a field finder tool to assist
the user in finding the job closest to the vehicle's location. With GPS
acquired, the job pick list will be updated every ten seconds. During
this update, the list of jobs is sorted by distance and the closest two
jobs are displayed on the top of the list. The remaining jobs are listed
beneath these.
To continue the existing job:
, press DOWN arrow
1. On the Home screen
list of jobs saved in the console.
2. Select the job name to be started/continued.
3. Press .
Start Job
The console will jump to Vehicle View and begin providing navigation
information.

Distance

If a selected job is in a UTM zone other than the current or adjacent
UTM zone, "Out of Range" will be displayed next to Distance, and
will be disabled.
Start Job
NOTE: For more information, see the UTM Zone Appendix.
If a selected job has no recorded information, Distance will show "No
Data".
Close Job
To close a job:
1. On the Home screen , press
To create a report of the job when closing a job:
1. Insert a USB drive into the USB port of the console.
2. On the Home screen , press
3. Select:
►Yes – to create a report of the last job
►No – to return to the Home screen without saving
.
New Job
to access the
.
Close Job
.
Close Job
