Display

Display is used to configure color scheme and LCD brightness,
establish screenshot availability and calibrate the touchscreen.
1. Press CONSOLE side tab
2. Press .
Display
3. Select from:
►Color Scheme – used to choose the color scheme that is
easiest to read
►LCD Brightness – used to adjust the brightness of the console
display
►Screenshot – used to allow screen captures to be saved to a
USB drive
►Screen Calibration – used to calibrate the touch screen
4. Press RETURN arrow
to the main Console Settings screen.
Figure 4-35: Display Options
Matrix® Pro 570GS ● Matrix® Pro 840GS
.
or CONSOLE side tab to return

Cultural

Cultural is used to configure units, language, and time zone settings.
1. Press CONSOLE side tab
2. Press .
Cultural
3. Select from:
►Units – used to define the system units
►Language – used to define the system language
►Time Zone – used to establish the local time zone
4. Press RETURN arrow
to the main Console Settings screen.
Figure 4-36: Cultural Options
.
or CONSOLE side tab to return
