Restart Demo GNSS

Demonstration GNSS can be restarted.
1. Press CONSOLE side tab
2. Press .
Demo GNSS
3. Press .
Restart
4. Press RETURN arrow
to the main Console Settings screen.
Figure 4-39: Restart Demo GNSS

Feature Unlock

Feature Unlock is used to unlock advanced features.
NOTE: The unlock code is unique for each console. Contact TeeJet
Technologies Customer Service. Once unlocked, a feature
remains unlocked unless the console is fully reset.
1. Press CONSOLE side tab
2. Press .
Feature Unlock
3. Press the locked feature button
►BoomPilot for Spreader – allows for spreader application
options when used with a compatible spreader implement
►FieldPilot Pro / UniPilot Pro – allows for AutoSteer options
when using a SCM Pro
►Third-Party Rate Control – allows for rate control options
when used with a compatible third-party rate controller
4. Enter unlock code if required.
5. Restart the console.
Matrix® Pro 570GS ● Matrix® Pro 840GS
.
or CONSOLE side tab to return
.
. for the locked feature:
Figure 4-40: Feature Unlocked
Enter Unlock Code
1 2 3
6 7 8
A B C
Unlock Successful!
The BoomPilot for Spreader feature
is now unlocked. Please reboot
console to begin using BoomPilot for
4 5 Clear
9 0 <--
D E F
Spreader.
31
98-05273-ENUS R6
