Reports

Reports is used to create job reports and save them to a USB drive.
NOTE: If Simple Job Mode is selected in the Options page, only the
current job can be saved.
When a job is active/started, Reports are not available for
selection. Stop the current job to enable the function.
When closing a job with a USB drive in the console, you get
the option to create a report on the current job.
1. Press DATA MANAGEMENT side tab
2. Press .
Reports
3. Insert a USB drive into the console.
4. Select the job to be saved.
5. Select:
►PDF
– report for print
PDF
►KML
– Google Earth Map
KML
►SHP
– ESRI shape data
SHP
►ALL – all available file types
PDF
6. Press RETURN arrow
to return to the main Data Management screen.
tab
ALL PDF KML
NOTE: The file icons
selection (grayed out) until a USB drive is inserted properly.
Figure 4-27: Reports – Advanced Job Mode
Matrix® Pro 570GS ● Matrix® Pro 840GS
.
or DATA MANAGEMENT side
SHP
or buttons are not available for
Figure 4-28: Reports – Simple Job Mode

Options (Job Mode)

Options allows the operator to select between Simple or Advanced
Job Mode.
NOTE: When a job is active/started, changing the job mode is not
available. Stop the current job to enable the function.
WARNING! Changing job modes deletes all internal job data.
1. Press DATA MANAGEMENT side tab
2. Press .
Options
3. Press DOWN arrow
to access the list of options.
4. Select:
►Simple – only bounded area and coverage areas are
displayed on the home screen. Only the current job is
available for saving in Reports. Use with Fieldware Link is
not available.
►Advanced – more than one job will be available at any time.
Client, farm, field and job names; bounded and coverage
areas; application time; and distance from selected job are
displayed on the home screen. All saved job profiles can be
exported as a PDF, SHP or KML file to a USB drive using
Data -> Reports.
● Client information, farm information, field information, and
prescription maps can only be inputted using Fieldware
Link. A job name can only be edited using Fieldware Link.
● A user can duplicate jobs for reuse of boundaries,
guidelines, coverage data and prescription maps using
Fieldware Link or Data -> Job Data -> Manage in the
console.
.
25
98-05273-ENUS R6
