Audio Volume; Demo Gnss - TeeJet Technologies MATRIX PRO GS User Manual

Matrix® Pro 570GS ● Matrix® Pro 840GS

Audio Volume

Audio Volume adjusts the volume level of the audio speaker.
1. Press CONSOLE side tab
Audio Volume
2. Press .
3. Press:
►UP arrow
to increase the sound
►DOWN arrow
to soften the sound
4. Press RETURN arrow
to the main Console Settings screen.
Figure 4-37: Audio Volume Options
30
www.teejet.com
.
or CONSOLE side tab to return

Demo GNSS

Demo GNSS is used to start the playback of a simulated GNSS
signal.
WARNING! This tool will disable incoming GNSS positions and begin
playing back simulated data. A console reboot is necessary
in order to restore real GNSS.
1. Press CONSOLE side tab
2. Press .
Demo GNSS
3. Press .
Start
4. Press RETURN arrow
to the main Console Settings screen.
NOTE: A console reboot is necessary in order to restore a real
GNSS.
Figure 4-38: Demo GNSS
.
or CONSOLE side tab to return
