DATA MANAGEMENT

Data Management allows for transfer and management of job
data, reporting of job data, changing of job mode, and transfer and
management of machine settings.
1. Press SYSTEM SETUP bottom tab
2. Press DATA MANAGEMENT side tab
3. Select from:
►Job Data – in advanced job mode, used to transfer job
information (delete, import, export) and manage job
information (create a new job, delete a job, or copy
a job's Guidelines, Boundaries, Applied Data, and/or
Prescription Map to a new job)
►Reports – used to create job reports and save them to a
USB drive
►Options – used to select simple job mode or advanced
job mode
►Machine Settings – used to transfer machine settings (delete,
import, export) and manage machine setting (create a new
machine setting, copy a machine setting, delete a machine
setting, save the current machine setting to the selected file,
or load the selected file's machine setting)
Figure 4-22: Data Management Options

Job Data

When in advanced job mode, job data options are used to transfer
job information (delete, import, export) and manage job information
(create a new job, delete a job, or copy a job's Guidelines,
Boundaries, Applied Data, and/or Prescription Map to a new job).
Job Data includes:
• Job name
• Client, Farm, and Field names
• Boundary
• Coverage Area
• Guidelines
• Maps (Coverage, Prescription, Application, Preset Target Rate)
• Tip Faults
Matrix® Pro 570GS ● Matrix® Pro 840GS
1. Press DATA MANAGEMENT side tab
2. Press
3. Select from:
.
.
4. Press RETURN arrow
Figure 4-23: Job Data Options

Job Data Unavailable

When in simple job mode, job data options will not be available.
Figure 4-24: Job Data Unavailable
.
Job Data
►Transfer – when in advanced job mode, allows the transfer of
selected jobs to or from a USB drive, as well as deleting jobs
►Manage – when in advanced job mode, allows the creation
of a new empty job, copying of a selected job's Guidelines,
Boundaries, Applied Data, and/or Prescription Map to a new
job, as well as deleting a selected job
or DATA MANAGEMENT side
to return to the main Data Management screen.
tab
.
