Figure 7-35: Prescription Map
27.00
Mark A
ac
Figure 7-36: Application Map
27.00
Mark A
ac
Figure 7-37: Target Rate Map
27.00
Mark A
ac
Matrix® Pro 570GS ● Matrix® Pro 840GS
10.0
mph
RealView Guidance allows live video input to be displayed instead
of a computer-generated image. RealView setup options accesses
additional guidance tools including guidance over video and a
steering angle indicator.
►Single Camera – a single camera is directly attached to the
►Video Selection Module – if a Video Selection Module (VSM)
10.0
mph
To adjust the camera view [reverse, upside down], go to Setup->
Configuration-> Video.
To access the RealView options:
1. Press REALVIEW GUIDANCE bottom tab
2. Press REALVIEW OPTIONS tab
options.
3. Select from:
►Single Camera View
10.0
mph
►Split Camera View
►RealView Guidance Options
►RealView Camera Image Capture
Figure 7-38: RealView Guidance

REALVIEW SPECIFIC OPTIONS

console
is installed on the system, two (2) video options are available:
• One Camera View – one of up to eight camera inputs can
be selected to change the view of the video input.
• Split Camera View – one of two sets of four camera inputs
(A/B/C/D or E/F/G/H) can be selected to divide the screen
into four separate video feeds.
[VSM only] – one (1) of up to eight
(8) camera inputs can be selected to change the view of the
video input
[VSM only] – one (1) of two (2) sets of
four (4) camera inputs (A/B/C/D or E/F/G/H) can be selected
to divide the screen into four separate video feeds
guidance tools including guidance over video and a steering
angle indicator
the current view on the screen to a USB drive
10.0
0.0
mph
98-05273-ENUS R6
.
to display RealView
– accesses additional
– saves a still photo of
27.00
ac
