Matrix® Pro 570GS ● Matrix® Pro 840GS

BOOMPILOT

Depending on if there is a section control system present and when
present what kind of section control is being used as well as what
options are enabled, there are multiple options for BoomPilot section
control. The settings of BoomPilot Start Mode and BoomPilot Icon
change how section control is handled on the guidance screens.
1. Press CONFIGURATION side tab
2. Press .
Implement
3. Select from:
►BoomPilot Start Mode – used to enable automatic BoomPilot
activation by speed (otherwise manually by icon)
►BoomPilot Icon – used to activate icon for manually controlling
BoomPilot
4. Press RETURN arrow
return to the main Configuration screen.
54
www.teejet.com
.
or CONFIGURATION side tab

BoomPilot Start Mode

BoomPilot Start Mode is used to set if the BoomPilot control is
started automatically by speed, or manually by the BoomPilot icon.
1. Press CONFIGURATION side tab
2. Press .
Implement
3. Press DOWN arrow
◄Off – BoomPilot will be controlled by the BoomPilot icon in the
Navigation and Guidance options on the guidance screens
◄Automatic – BoomPilot will be controlled by speed
Figure 6-36: BoomPilot Icon
to
.
to select Off or Automatic.
