TIP SELECTION

When the system includes a Pressure Sensor Interface Kit (PSIK),
Tip Selection is used to select the type of sprayer tip (series and
capacity) for determining droplet size information.
1. Press CONFIGURATION side tab
2. Press .
Implement
◄Current Tip selection is shown in the information box
3. Press Tip Selection NEXT PAGE arrow
4. Select from:
►Tip Preset 1-5 – selects up to five (5) tips for quick recall,
and selected the current tip for determining droplet size
information
►Current Tip – displays the current tip
5. Press RETURN arrow
return to the main Configuration screen.
Figure 6-30: Droplet Size Monitor
Matrix® Pro 570GS ● Matrix® Pro 840GS
.
.
or CONFIGURATION side tab

Preset

Tip presets allow saving of up to five tips for quick recall.
1. Press .
+
2. Select a TeeJet tip series.
3. Select tip capacity.
Figure 6-31: Preset Tip
to
