Specifications - Aim Lab PathFinder 350S User Manual

2.

Specifications

The table below outlines the specifications of the PathFinder 350S. Aim Lab Pty Ltd
reserves the right to change these specifications at any time without notice.
Footprint
Shipping Dimensions
Module Net Weight
Shipping Weight
Power Supply
Air Supply
Mains Input Fuse Rating
DC Output Fuse Rating
User Interface
Monitor
Temperature Range: Non-operating
Temperature Range: Operating
Max number of Specimens
Maximum Throughput
Tube Dimensions
Tube Identification
Supported Barcode Formats
Rack Capacity
Rack Types
03P27-42 Rev A
100cm L x 45 cm W x 52 cm H (40" x 18" x 21").
Multiple boxes totalling 0.7m
Sorter Module 30Kg (66 lbs).
Services Module 10Kg (22 lbs).
Specimen Tray 5Kg (11 lbs).
Approximately 76 Kg (167 lbs).
100 – 240VAC, 50-60Hz, 250 W, 24VDC output.
No manual voltage adjustments are required.
4 bar filtered and regulated output (self supplied).
6-8 bar auxiliary input.
5A slow blow.
10A slow blow.
Touch-screen LCD monitor. Optional USB keyboard.
800 x 600 DPI LCD TFT monitor. 4-wire resistive
touch screen – USB.
o
5 C – 40
20 – 80% relative humidity, non-condensing.
o
10
8 – 80% relative humidity, non-condensing.
250 when using 5 x 50way PathFinder racks.
Up to 350 specimens per hour.
12-16mm OD, 63 – 120mm height.
CCD barcode reader.
Code 39 Family (with check digit).
Code 128 Family (including EAN and ISBT).
CODABAR Family (with start/stop control).
Interleaved 2/5 (with check digit).
EAN/UPC without ADD-ON.
Up to 5 PathFinder 50 way racks + Error/Stat rack.
Up to 9 PathFinder 20 way racks + Error/Stat rack.
Or combinations of 50 and 20 way racks.
PathFinder 50 and 20 way racks. Various third-party
analyser racks are supported with the use of rack
adaptors.
© Copyright 2010 Aim Lab Pty Ltd
PathFinder 350S User Manual
o o o
C ( 41 F – 113 F ).
o o o
C – 35 C ( 50 F – 95 F ).
3
.
Page 19
