Figure 6-39 is an example of the unfiltered report.
6.9.2.5
A profiles configuration report shows all profile identifiers and both short and long
descriptions. Figure 6-40 is an example of the unfiltered report.
03P27-42 Rev A
Figure 6-39 Example Profile Gates Report
Heading
Profile ID
Tray
Gate Index
Direction
Description
Profiles
Figure 6-40 Example Profiles Report
© Copyright 2010 Aim Lab Pty Ltd
Description
Name of the profile.
Name of the tray.
Gate on the tray.
Whether the gate is an input or an output.
Description of the location ID.
