Inspection and Unpacking

3.1

External Damage Check

Check the shipping cartons for any external signs of damage. If the cartons show
any sign of damage then contact the supplier immediately.
3.2

Unpacking

It is a requirement of warranty that, should it be necessary to return the equipment
during the warranty period, the equipment is repacked in the original packaging.
All items should be unpacked, placed on a suitable bench and checked against the
packing list.
Report any discrepancies to the supplier immediately.
3.3

Modules

The PathFinder 350S is made up of a number of modules. A module is a functional
unit within the PathFinder 350S that can be deployed and replaced as a single
component.
The PathFinder 350S system consists of the following modules.
3.3.1

Sorter Robot

The Sorter robot does the physical work of picking and placing specimens into the
appropriate racks. It is the primary module to which the other modules attach.
It contains the control PC (workcell controller) that co-ordinates all the modules.
The workcell controller interfaces to the LIS/Middleware software to determine the
correct destination for the specimen. It interfaces to the operator via the LCD
monitor which is also mounted on the Sorter.
03P27-42 Rev A
Retain the PathFinder 350S shipping carton for later use should it be
required.
A minimum of two (2) people are required when carrying and
unpacking the PathFinder 350S due to its size and weight.
