2.

Specifications

The tables below outline the specifications of the PathFinder 350S.
Aim Lab Pty Ltd reserves the right to change these specifications at any time
without notice.
2.1

General Specifications

Shipping Dimensions
Module Net Weight
Shipping Weight
User Interface
Temperature range: Non-operating
Temperature range: Operating
Maximum Thermal Output
Maximum Sound Power Levels
Max number of Specimens
Maximum Throughput
Tube Dimensions
Tube Identification
Supported Barcode Formats
Rack Capacity
Rev E February 2010
Item
Footprint
Air Supply
© Copyright 2010 Aim Lab Pty Ltd
Specification
100cm L x 45 cm W x 52 cm H (40" x 18" x 21")
Multiple boxes totalling 0.7m
Sorter Module 30Kg (66 lbs)
Services Module 10Kg (22 lbs)
Specimen Tray 5Kg (11 lbs)
Approximately 76 Kg (167 lbs)
4 bar filtered and regulated output. (Self Supplied)
6-8 bar auxiliary input.
Touch-screen LCD Monitor.
Optional USB Keyboard.
o o
5 C – 40 C (41
20 – 80% RH non-condensing
o o
10 C – 35 C (50
8 – 80% RH non-condensing
Approximately 200W
<60dB at 1m.
250 when using 5 x 50way PathFinder Racks
Up to 350 specimens per hour.
12-16mm OD, 63 – 120mm Length
CCD Barcode Reader
Code 39 Family (with check digit)
Code 128 Family (incl. EAN and ISBT)
CODABAR Family (with start/stop control)
Interleaved 2/5 (with check digit)
EAN/UPC without ADD-ON
Up to 5 PathFinder 50 way racks + Error rack
Up to 9 PathFinder 20 way racks + Error rack
PathFinder 350S Service Manual
3
o o
F – 113 F)
o o
F – 95 F)
