PathFinder 350S User Manual
The remote interface is accessed by typing the IP address of the PathFinder 350S in
the following format into the address bar of your browser:
[IPADDRESS]:8080/PFS
For example:

Figure 6-3 Remote Interface Access

The IP address will be determined by the installation and the IT department in your
laboratory.
6.3

Login Page

The login page is the first screen presented to the user. Login by entering your user
name and password into the fields provided. The user can use a keyboard attached
to the Sorter or the virtual keypad provided on the screen.
Note: the remote access login does not have a virtual keypad.
The Shutdown button will close the workcell controller programs and shutdown the
embedded PC.

Figure 6-4 Login Page

03P27-42 Rev A © Copyright 2010 Aim Lab Pty Ltd Page 43
