These settings refer to the two LIS interfaces available on the PathFinder 350S. For
more information on these interfaces and how they differ, refer to the LIS Interface
Manual.
Configuration Item
My Password for
Transmit Messages
Path of Transmit
Directory
Path of Receive
Directory
Version Number
Transmit File
Extension
Debug Switch
Receive File
Extension
My ID for Transmit
Messages
Descriptive Text of
Control Element
Communications Log
Switch
Processing Mode
Remote Password for
Received Messages
Remote ID for
Received Messages
Main Switch
03P27-42 Rev A
The password sent to the LIS.
The path where the Sorter will place files for the interface.
Note: do not use backslash ( \ ). If mapping to a network address, map the
location as a drive and use a standard path.
The path where the LIS will place files for the Interface.
Note: do not use backslash ( \ ). If mapping to a network address, map the
location as a drive and use a standard path.
The LIS interface version number to report to the LIS.
The extension used on the files sent to the LIS. For example .txt or .dat.
Turn on LIS debugging messages. These are logged in the messages log. If
not actively debugging the LIS interface, this should be set to 0.
The extension used on the files sent from the LIS. For example .txt or
.dat.
The ID used in the LIS messages to identify the PathFinder 350S.
A meaningful name for the LIS interface.
This allows LIS message logging to be enabled or disabled. It is on by
default.
This is used to identify LIS messages as a test message or a production
message.
The password expected in incoming messages, i.e. from the LIS.
The ID expected in incoming messages, i.e. ID of the LIS.
This enables or disables the LIS interface.
