Examples of Tricefy™ icons displayed on screen

Using Tricefy™

11.2.3.6 Backup

11.2.3.6.1 System Configuration

Voluson™ SWIFT / Voluson SWIFT+ Instructions For Use
5831612-100 Revision 4
The tab displays a general info area with a short description of Tricefy™, an uplink ID and an
info badge for how to configure P-buttons int the system setup (only available when an
account is active). Furthermore the account area displays controls and information about the
Tricefy™ account while the test connection area enables to test a connection and gives
detailed information about it.
Depending on the Tricefy™ status and actions following icons are displayed:
Connected to Tricefy™, ready to store and share.
Disconnected from Tricefy™.
Registration incomplete.
Upload of e.g. an image to Tricefy™.
Share an image with a patient via Tricefy™.
1. To enable Tricefy™ check
Tricefy™ items are displayed (e.g. email text field, Activate button,.... and options within
the system setup to share or store data to Tricefy™ via P-button, status bar icons,...).
2. Enter your email address to register and click
an active account, click
3. Depending on the account status, different account information is displayed:
•
green badge containing the account info, email address, account name, customer
name and account status- account activated
•
blue badge - information about a disconnected account
•
orange badge - connection to Tricefy™ failed (due to timeout,...)
4. For testing the connection click
different information is displayed:
•
green badge - connection ok
•
blue badge - instruction for testing the connection (only displayed as long as
Connection is not pressed)
•
orange badge - connection failed
The Backup function is the only tool to backup and reload the
Image Archive .
A backup can only be started without an exam or reloaded data set being open .
System Configuration contains all system settings like user programs, text auto, setup
The
parameters (DICOM configuration, measure setup, network) etc.
Enable Tricefy™ . As soon as this option is enabled, relevant
Activate account . (If you want to deactivate
Deactivate account .)
Test Connection . Depending on the connection status,
System Setup
Test
System Configuration and
11-39
