Archive

9.4.2 Past Exam

Controls
Past Exam Data shown from
to
Exam Date
Measurement Fields
Up/Down
Add
Delete
Cancel
Save & Exit
Fetus A/B/C

9.5 Clipboard

Clipboard Screen layout
9-20
Past Exam to open the Past Exam dialog. This dialog is used to enter data from
Press
previous ultrasound exams performed on other systems. Only available when OB is selected.
Shows data starting at this date.
Shows data ending at this date.
Create a new entry by entering an exam date.
Enter measurement data from previous exams performed on different systems.
Swipe up/down to scroll through the list.
Add a new line if the available lines are filled.
Delete the selected line in all fetuses. A warning appears.
Return to the patient dialog without saving data.
Return to the patient dialog and save data.
Switch between the fetuses.
The Clipboard displays stored US data of the current exam as preview images Pressing one of
the P-buttons stores active image information and displays a preview on the clipboard. This
implies that the respective button has been configured.
Images of other patients will not be saved onto clipboard. If you reopen and continue an old
exam, then the images of this exam will be displayed on the clipboard.
Screen layouts can be changed by touch gestures.
Pinch
Zooms out and makes the size of thumbnails on the
clipboard smaller.
Spread
Zooms in and makes the size of thumbnails on the
clipboard bigger.
The Clipboard is visible at evary mode except for
Within Measure and Annotation Text the Clipboard can be shown depending on the system
setup.
Figure 9-11 Past Exam
System Setup , Measure Setup , PID , Archive .
