3D and 4D Mode

Cut Mode

Defined Depth
Cut Undo
Depth

Using MagiCut

Trace Inside or Trace
1. Select
Outside .
2. Use the rotation controls to rotate
the rendered 3D image to a
position where 3D artifacts or
undesired information can be cut.
3. Enter the start point of the trace by
positioning the system cursor with
the trackball and press
4. Enter the trace with the trackball,
the trace is shown with a red line.
5. Enter the end point of the trace by
pressing
•
Cut Defined Depth
proceed with step 6
•
Cut Defiend Depth
with step 7
6. The trace closes from end to start
point and the cut action is
performed. The system cursor
appears again to start a new cut.
7. Adjust the wanted depth with the
Depth -control. The result of the
adjustment is shown in real-time
on the 3D image.
Done to end the cut
8. Press
process.

8.8.3 Cine Calculation

Note
8-30
•
Trace Inside : content inside the trace will be cut
•
Trace Outside : content outside the trace will be cut
•
Box Inside : content inside the Box will be cut
•
Box Outside : content outside the Box will be cut
•
Eraser Small : content along the entered trace (small width) will be cut
•
Eraser Big : content along the entered trace (big width) will be cut
Select one of the two possible cut depths.
•
Off : complete content over the whole depth is cut
•
On : content selected with the depth control is cut
•
Undo All Cuts : undo all done cuts
•
Undo Last Cut : undo the last cut
Adjust the depth.
Trace
1. Select
2. Use the rotation controls to rotate
3. Position the left upper point with
4. Move the point with the trackball in
Set .
5. Enter the box by pressing
Set .
Off :
On proceed
6. The cut action is performed. The
7. Adjust the wanted depth with the
8. Press
To get an overall 3D impression of the rendered object a certain number of calculated views
are displayed in a sequence. The rendered object rotates or moves in front of the observer.
Not all cine types are available in all visualization modes, see table below.
Box
Box Inside or Box Outside .
the rendered 3D image to a
position where 3D artifacts or
undesired information can be cut.
Set .
the trackball and press
a diagonal fashion to create a box.
The red trace of the box is
displayed immediately.
Set .
•
Off :
Cut Defined Depth
proceed with step 6
•
Cut Defined Depth On :
proceed with step 7
system cursor appears again to
start a new cut.
Depth -control. The result of the
adjustment is shown in real-time
on the 3D image.
Done to end the cut
process.
Voluson™ SWIFT / Voluson SWIFT+ Instructions For Use
Eraser
Eraser Small or Eraser Big .
1. Select
2. Use the rotation controls to rotate
the rendered 3D image to a
position where 3D artifacts or
undesired information can be cut.
3. Position the first point and press
Set .
4. Move the eraser over the part of
the image to be erased. The
entered trace is shown with a
black line in real time.
5. Press the right or left trackball key
Set to finish the cut. The region
underneath the eraser trace will be
cut from the 3D rendered image.
The system cursor appears again
to start a new cut action
