Display Modes; Screen Formats - GE Voluson Swift Instructions For Use Manual

Technical Data/ Information
Transducer types:
Operating modes:

13.4 Screen Formats

2D Imaging:
TL Imaging:
3D/4D Imaging.
Image Size

13.5 Display Modes

Real time simultaneous
capability:
Real time Triplex capability:
13-6
•
Linear Array
•
Volume probes "4D":
○ Convex Array
○
Microconvex Array
•
2D-Mode
•
M-Mode (conventional M-Mode)
•
PW Doppler Mode
•
Anatomical M-Mode (AMM)
•
CW Doppler Mode
•
High PRF Doppler Mode
•
Color Flow Doppler Mode (CFM)
•
Power Doppler Mode (PD)
•
HD-Flow™ Doppler Mode (HD-Flow™)
•
XTD-Mode
•
Contrast Agent Mode (Contrast)
•
M-Color Flow Modes (M/CF, M/HD-Flow™)
•
Volume Modes (3D/4D):
○
3D Static
○
4D Real Time
○
VCI-A
○
VCI- SingleView, OmniView(not available in all countries)
•
Single (2D*)
•
Dual (2D*+2D*)
•
Quad (2D*+2D*+2D*+2D*)
•
*2D = B, B-Flow, Contrast, B/CFM, B/PD, B/HD-Flow™
•
B+TL** (Top/Bottom): 3 format sizes: 40/60, 50/50, 60/40%
•
B+TL** (Side/Side): 50% / 50%
•
**TL = M, PW, CW, M/CFM
•
Render: quad (A/B/C/3D, dual (A/3D), single (3D)
•
Sect. Planes: quad (A/B/C), dual (A/B, A/C, Ref/Any Plane), single (Ref)
•
TUI: 1x1, 1x2, 2x2, 3x2,3x3, 3x4, 4x4
•
Segmentation: quad (A/B/C/Segm. Object), single (Segm. Object)
•
Standard format
•
in combination with SRI and/or CRI:
○
B/CFM, B/PD, B/HD-Flow™, 3D/CFM, 3D/PD, 3D/HD-Flow™,HD-Flow™, B+B/
CFM, B+B/PD or B+B/HD-Flow™
•
in combination with SRI:
○
2D+M, 2D+PW
•
in combination with SRI:
○ 2D/CFM+PW, 2D/PD+PW, 2D/HD-Flow™+PW, 2D+M/CFM, 2D+M/HD-Flow™
Voluson™ SWIFT / Voluson SWIFT+ Instructions For Use
5831612-100 Revision 4
