11.2.2.1 Service

Controls
Note

11.2.2.2 System Info

11.2.2.3 Options

Voluson™ SWIFT / Voluson SWIFT+ Instructions For Use
5831612-100 Revision 4
•
Debug
•
•
Service Tools
Display Service Tool functions (System Serial Number,
System Hour Meter, Auto Tester, Decrypt Disk,...)
It is possible to restore democases into the archive by
Note
pressing Restore Democases into Archive. When enough
space is available a progress bar appears displaying the
restore status. The democase patients are added to the
internal archive.
Generate NLS keys Export the NLS setting of the ultrasound device.
ASI
Install additional software from media, including Internal
HDD, Network, External USB Drives, R:Factory
For further details and explanations refer to the Service Manual of the system.
Figure 11-10 System Info
This tab gives information about the Software and Hardware System.
The button Patent Applications displays all the patents and applications the Voluson™
SWIFT / Voluson SWIFT+ system is protected with.
This page shows all available system options and their states.
D Demo
I Inactive
Mode State Display : Show current mode in image
window.
Image Boundary : Show a yellow line around the
ultrasound image.
4D Shift Control : Sets the 4D shift control to visible.
Shift control adjustment is performed in 4D-real time
mode. The determined shift control value is stored on
the probe device.
Option is activated for demo and expires on the
date shown in the "Valid" column.
Option is not activated.
System Setup
11-17
